Turbine Flow Hydraulic Conversion

Description

Perfect for energy conversion of the water into electrical energy mechanical equipment

Directly used to charge small battery, mobile phone, or power supply for LED lights, etc

Output current: Max. greater than equal 220mA

Line resistance: 10.5+/-0.5ohm

Insulation resistance: 10Mohm (DC100 megohmmeter)

Closed outlet pressure: Max. 0.6Mpa

Opened outlet pressure: Max. 1.2Mpa

Starting water pressure: 0.05Mpa

Axial clearance: 0.2-1.0mm

Mechanical noise: less than equal 55dB

Output characteristics: output voltage without the voltage regulator circuit is proportional to the water pressure

Installation: standard household 1/2 inch water pipe (Outer diameter:20mm, inner diameter:13mm)

voltage: 5V/12V/80V

colour:Transparent + yellow

Material:plastic

size:About 8.85.83.9cm

Package Contents:

1 * Generator

Only the above package content, other products are not included.

Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
